Elite Model 92 - Tool Sharpening w/ 2 CNC Axes
Heavy-duty universal tool and cutter sharpening machine
Description / Informational PDF
The Elite Model 92 is a universal tool and cutter grinding machine designed for sharpening woodworking tools such as milling cutters, drill bits, profiled blades, spinning top heads, and more. Built for precision and reliability, the Model 92 features a direct-drive grinding wheel motor with variable speed control, robust mechanical construction, and an easy-to-use design. Its spacious working table, combined with smooth X, Y, and Z axis movements on hardened ways and recirculating ball bearings, makes it ideal for a wide range of sharpening and grinding applications. Offering unbeatable quality and value, the Elite Model 92 has earned its reputation as our most popular universal tool and cutter sharpening machine for the woodworking industry.
Highlights
Direct-drive spindle with variable speed from 3,000 to 9,000 RPM (optional 18,000 RPM).
Heavy-duty working table with 220 lbs load capacity and triple "T" slots.
Smooth X, Y, and Z axis movements on hardened guides and ball bearings.
Compact design with 150mm grinding wheel and two adapters included.
Simple controls and robust construction for long-lasting performance.
Options / Accessories
Indexing head – MT 4
Grinding wheel holder 20mm
Tool holder
Drill grinding device
Motorized work head for cylindrical
Adjustable tailstock
Diamond grinding wheel
Complete coolant system
HMT CleanGrind Synthetic Coolant
